K-Suite 3.09

We are today introducing significant innovations regarding KESSv2 and K-TAG, which will provide new functionalities and tools to improve your work on many vehicles.



New protocols for KESSv2 and K-TAG



KESSv2

From now on, you’ll be able to work in OBD on Ford equipped with Continental SID208 and SID209, like 2017 Ford Ranger T6, and on the VAG equipped with Bosch MED17.1.1, Bosch MED17.1.62 and Bosch MED17.1.61, like 2018 Audi TT RS.
Also, new protocol via OBD even for GMC equipped with ECU Delco E86e, for example 2018 Chevrolet Silverado.

K-TAG

Microcontrollers involved in this update:

  • BOOTLOADER M32R
  • BOOTLOADER TRICORE
  • JTAG RENESAS
  • JTAG/BAM SPC
  • NEC NBD



The update involves not only Cars, but also Bikes and Tractors, some of these vehicles are brand new and awaited, like 2018 Suzuki GSXR-1000.

Possible connections on KESSv2 and K-TAG



OBD OBD Patch OBD Password OBD Virtual Reading Boot OBD Boot
Direct Connection



News for KESSv2 and K-TAG



Vehicle Ecu ECU Version Micro Make Method
Ac Delco E86 TC1797 Chevrolet
Bosch MED17.1.1 M&S TC1797 Audi
Bosch MED17.1.61 TC1793 Audi
Bosch MED17.1.62 TC1793 Audi
Continental SID208 TC1797 Land Rover
Continental SID208 TC1797 Ford
Continental SID209 Ford
Continental SIM2K-241  TC1767 Hyundai
Continental SIM2K-241 TC1738 Hyundai
Continental SIM2K-241  TC1767 Kia
Continental SIM2K-260 Hyundai
Continental SIM2K-260 Kia
Continental SIM2K-305 Hyundai
Continental SIM2K-305 Kia
Continental SIM2K-341 TC1738 Hyundai
Delphi DCM3.7 Chevrolet
Delphi DCM3.7 Daihatsu
Delphi DCM3.7 Holden
Delphi DCM3.7 Seat
Delphi DCM3.7 Skoda
Delphi DCM3.7 Volkswagen
Denso 112431-4840 Scion
Denso 112431-4840 Subaru
Denso 112431-4840 Toyota
Denso 275036-1150 76F0039GD Toyota
Denso 275036-5280 (CAN) 76F0085 Toyota
Denso MB279700-9621 Volvo
Denso SH1 Mazda
Denso SH72543 Subaru
Hitachi DEF003 SH72543 Subaru
Transtron 4Jxx Isuzu
Transtron 4Jxx Isuzu
Valeo V50 Dacia
Valeo V50 Renault
Valeo VD46.1 Peugeot
Denso 32920-17Kxx Suzuki
Denso 32920-17Kxx TC Suzuki
Caterpillar A5X12I1 Orvex
CNH KUBOTA 1851862-30 Case Ih
Delphi DCM3.3 SH72543 JCB
Denso 275722-7380 Kubota
